Construction
AA West uses M10 ferrules. All concrete treads come with a brush-and-edge finish.
Strength
High-strength concrete
Reinforcement
8mm trench mesh
Fittings
Adjustable M10 ferrules
Finish
Brush-and-edge finish
OVERVIEW
Reinforced treads for steel stringers.
Concrete stair treads are intended for steel stringers, designed with ferrules for easy fixing, reinforced with 8mm trench mesh and manufactured to a high-strength concrete rating. Ferrule locations can be adjusted to suit your design.
SPECIFICATION
Product dimensions, finishes and practical details.
Standard sizes
- 914 × 300 × 50mm
- 1000 × 300 × 50mm
- 1065 × 300 × 50mm
- 1220 × 300 × 50mm
- 1065 × 250 × 50mm
- 1065 × 350 × 50mm
- 1500 × 300 × 75mm
Custom sizes and finishes
Made-to-size treads are available. Custom mould fabrication may be charged to the customer; polished and exposed aggregate finishes are available.
